Goldfield Weighing Solutions

ABS Mini Table Top Scale

Price : 1,275.00 - 2,950.00 / Piece
Get Best Price

MOQ : 1 Piece

Business Type Manufacturer, Exporter, Supplier, Retailer, Wholesaler, Trader, Distributor, Importer, Buying House
Country of Origin India
Type Table Top Scales
Certification CE Certified, ISO 9001:2008
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Application
Weight Measuring
Weight
1-10kg
Color
Grey, Light White, White
Voltage
220V
Condition
New
Display Type
Digital LED
Capacity
100-200kg
Automatic Grade
Semi Automatic
Power
3-6kw
Driven Type
Battery, Electric
Power Supply
230 V AC Mains
Warranty
1 Year Against Any Manufacturing Defects
Accuracy
0.5/1/2/5 G
Brand Name
GOLDFIELD
Rated Load
4 To 5 Kg
Brand
Goldfield
Type of Weighing Scale
Table Top Scale
Model Name / Number
GMS 5/10/20
Max. Weighing Capacity Kg
5/10/20 Kg
Least Count / Accuracy
0.5/1/2/5 g
Internal Resolution
1,60,00,000
Display Resolution
2,92,000
Display / Digit Type
0.56” Seven Segment
Display Size
14 / 18 mm
Display Led Color
Bright Red / Green
Material of Construction
Virgin ABS/PVC
Platter Size
170 x 230 mm
Platter Type
Stainless Steel Pan
Mode of Operation
Kg / Gram / Liter / Piece
Usage / Application
Personal & Commercial
Body Color
NA / Siemens Gray
Frequency Supply
50Hz, ±10%
Working Temperature
Normal / Room Temperature (0 to 45˚ C)
Features
Standard Weighing Scale
Battery Type
Rechargeable Battery
Ip Rating
IP65
Operating Temperature
0˚ C to 45˚ C
Platform Surface
Plain
Portable
Yes
Response Time
50 mSec to 70 mSec
Taring Range
Taring Range
Battery - Backup Time
24 Hours
Battery - Stand By Time
Up to 100 Hours
Class
II / III
Design
Rough & Tough
Humidity
10% to 95% Relative humanity (Non-condensing)
Linearity
99.9% of the Rated capacity ±1%
Mounting Type
Table / Floor Mounting
Number of Batteries
1
Number of Digits
6
Number of Switch Keys
4
Rated Output
3.01 mV/V
Non-linearity
0.02 %FS
Hysteresis
0.02 %FS
Repeatability
0.019 %FS
Creep
0.018 %FS/30 min
Temperature Effect On Zero
0.016 %FS/10˚ C
Temperature Effect On Span
.017 %FS/10˚ C
Zero Balance
±1.016 %FS
Input Resistance
350 Ω ±5%
Output Resistance
400 Ω ±5%
Insulation resistance
≥5000 MΩ (50 VDC)
Recommended Excitation Voltage
9~12 VDC
Allowed Excitation Voltage
5~18 VDC
Compensated Temp. Range
-10˚ C ~ +40˚ C
Operating Temp. Range
-20˚ C ~ +55˚ C
Safe Overload
120 %FS
Ultimate Overload
150 %FS
Overload Protection
Yes
Shock Load Protection
Yes, Through Hardware
Calibration
Auto Calibration with External Weight
Total Weight
1.5 to 3 Kg
Product Code
01
Port
Mazgaon
Payment Terms
Other
Delivery Time
Immediate
Packaging Details
Thermocol in corrugated Box

Unique Features:

  • ABS body in compact and light in weight.
  • Front-Back Display for customer view.
  • Rough and Tough model for daily uses.
  • Cut/Pencil size Aluminium Load cell.
  • 4/6 Volt PTH type Glass Epoxy Motherboard with High Sensitivity Features.
  • AVIA technology base 24 Bit delta-sigma ADC for higher resolutions.
  • Advanced Micro Controller technology base Mother Board.
  • 14/18 mm Bright Red/Green LED Display with High Brightness.
  • Lacquer Protected Motherboard to Avoid Moisture.
  • Auto Standby Mode for Low Power Consumption.
  • Linearity from least count to full capacity.
  • Simple and Instant Operation.
  • Auto Zero Tracking System.
  • Tare Weight Facility.
  • Auto Power Saver.
  • Easy to operate.
  • User Friendly
  • The best battery backup than other cards.
  • 4/6 Volt & 4.5/5 Ah Battery for more Back up.
  • Also available in OEM base.

Yes! I am interested


Technical Specification

Model Cap/Acc Pan Size
GHS 5 5Kg/0.1g 170 X 230 mm
GMS 5 5Kg/0.5g 170 X 230 mm
GMS 10 10Kg/1g 170 X 230 mm
MS 20 20Kg/2g 170 X 230 mm
GMS 30 30Kg/5g 170 X 230 mm
